Product overview

Name Thioflavin X (ThX)
Biological description

Novel, next generation blue-green, cell-permeable fluorescent amyloid stain. Shows 5x increase in brightness and 7x increase in binding affinity to amyloidogenic proteins (α-syn) to display superior photophysical and binding properties compared to Thioflavin T (ThT). Thioflavin X (ThX) outperforms Thioflavin T as a single-aggregate probe of β-Amyloid Peptide (1-42) (human) and P301S tau as ThX is able to detect greater numbers of fluorescent species of each than ThT.

Unlike Thioflavin T, Thioflavin X (ThX) can be used for monitoring structural changes of amyloid β oligomers. The improved optical properties (extinction coefficient, quantum yield and brightness) of Thioflavin X (ThX) allow monitoring of structural differences in oligomeric species which is not observable with Thioflavin T imaging. It is suitable for studying unique structural amyloid features in bulk and on a single-aggregate level and also allows detection of amyloid β-sheet species at the early stages of protein aggregation. Also used to super-resolve the structures of tau aggregates (especially early aggregate species with lengths under 100-200 nm). Suitable for use in super-resolution microscopy with ~20nm resolution.

β-Amyloid Peptide (1-42) (human) also available.

Purity >97%
Description

Next generation, cell-permeable fluorescent amyloid stain with superior photophysical properties compared to Thioflavin T

Write Your Own Review
You're reviewing:Thioflavin X (ThX)
Rate this item:

Optical Data

Max excitation wavelength 420nm
Max emission wavelength 494nm
Quantum Yield (φ) 0.04
Extinction Coefficient (ε) 31130

Solubility & Handling

Storage instructions -20°C
Solubility overview Soluble in DMSO (100mM) and in EtOH (10 mM)
Handling

Needham et al prepared stock solutions to 10mM in DMSO. These were then diluted into 0.02µM filtered PBS (pH 7.4) to the experimentally required concentration.

Important This product is for RESEARCH USE ONLY and is not intended for therapeutic or diagnostic use. Not for human or veterinary use

Calculators

Molarity

=
x
x
More Info

Dilution

x
=
x
More Info

Chemical Data

Purity >97%
Chemical name 6-methoxy-3-methyl-2-(4-pyrrolidin-1-ylphenyl)-1,3-benzothiazol-3-ium iodide
Molecular Weight 452.35
Chemical structure Thioflavin X (ThX) [2683063-26-3] Chemical Structure
Molecular Formula C19H21IN2OS
CAS Number 2683063-26-3
PubChem identifier 170907366
SMILES [I-].COC1=CC2=C(C=C1)[N+](C)=C(S2)C1=CC=C(C=C1)N1CCCC1
Source Synthetic
InChiKey IJDBRVINIKHPDK-UHFFFAOYSA-M
Appearance Orange solid
Excitation 420
Emission 494

References for Thioflavin X (ThX)

References are publications that support the biological activity of the product
  • Cavity Lasing Characteristics of Thioflavin T and Thioflavin X in Different Solvents and Their Interaction with DNA for the Controlled Reduction of a Light Amplification Threshold in Solid-State Biofilms.

    Rusakov K et al (2023) ACS applied optical materials 1 : 1922-1929
  • Hyperphosphorylated tau self-assembles into amorphous aggregates eliciting TLR4-dependent responses.

    Meng JX et al (2022) Nature communications 13 : 2692
  • ThX - a next-generation probe for the early detection of amyloid aggregates.

    Needham LM et al (2020) Chemical science 11 : 4578-4583
